Drumport Stompbox Converter

Stompbox Converter

The Stompbox Converter can be connected between any standard stompbox (e.g., Shadow, Ortega, Meinl, Logjam Logarhythm) and any amplifier using a standard jack cable. The Stompbox Converter offers 12 different sample sounds that can be directly selected via a rotary control; the sensitivity can be adjusted to suit the stompbox in use using a second control. The device is powered by an external power supply.

The sounds

• Pickup stompbox

• Microphone Stompbox • Cajon Bass
• Bass Drum 1
• Bass Drum 2
• Bass Drum 3
• Snare
• Hi-Hat
• Cowbell
• Tambourines
• Cabasa
• Handclap

Technical data

• Selector switch: 12 sounds
• Sensitivity control: for adjustment to the stompbox used
• Microprocessor controlled
• Real sample play
• Die-cast aluminum housing
• Dimensions: 110 x 60 x 30 mm
• Weight: approx. 200 g
• Anti-slip coating
• Output: 6.3 mm unbalanced (device is plugged in and switched on) • Input: 6.3 mm unbalanced
• DC socket: for 9 V power supply (- pin / + outside)
• CE, ROHS, Made in Germany

Manufacturer information:

Drumport UG (limited liability), Grenzstr. 21, 56077 Koblenz, Germany

peter@drumport.de, www.drumport.de

Safety and warning information:

The product’s safety instructions can be found in the operating instructions.
